Reliable power control for your marine vessel
The Blue Sea M-Series Battery Switch is the ultimate choice for boat owners demanding reliable power management. This compact switch ensures dependable battery isolation and control, giving you peace of mind whether you're out cruising or just docked. Its IP66 waterproof rating means it's fully protected against powerful water jets, making it ideal for the splashes and spray common in New Zealand conditions, while also being ignition protected for safe installation on gasoline-powered boats.
It features tin-plated copper studs for maximum conductivity and superior corrosion resistance – vital for saltwater longevity. The one-piece terminal stud design eliminates loosening over time, ensuring a secure and lasting connection for your electrical system. With a substantial 300A continuous rating and a mighty 1000A cranking rating (30 sec), this switch handles serious power demands with ease. Its versatile design allows for surface, rear or front panel mounting, and the 7/8" (22mm) stud length accepts multiple cable terminals, simplifying installation. Plus, an isolating cover with snap-on sections keeps rear contacts protected, enhancing overall safety aboard your vessel.
Blue Sea M-Series Battery Switch Features:
- Tin-plated copper studs for maximum conductivity and corrosion resistance
- Studs accept 3/8" (M10) ring terminals
- 7/8" (22mm) stud length accepts multiple cable terminals
- One-piece terminal stud design never loosens over time
- Isolating cover with snap-on sections protects rear contacts
- Case design allows surface, rear or front panel mounting options
- Waterproof: rated IP66 from water projected in powerful jets
- One-piece stainless flange nuts ensure safe and secure connections
- Breakout tabs allow wire access in any direction
- Ignition protected—safe for installation aboard gasoline powered boats
- Switches a single battery to a single load group
Blue Sea M-Series Battery Switch Specifications:
- Model: 6006200-BSS
- Switch type: Single Circuit ON-OFF
- Colour: Black
- Switch positions: 2
- Battery combine: No
- Alternator field disconnect: No
- Maximum Voltage: 48VDC
- Stud size: 3/8"
- Terminal stud torque: 120 in-lb (13.56 Nm)
- Continuous rating: 300A
- Intermittent rating: 500A (5 min)
- Cranking rating: 30 sec 900A
- Battery inputs: 1
- Cable clearance for 4/0 AWG cables: 1.12in (28.45 mm)
- Cable size to meet ratings: 4/0 AWG (120mm)
- Mounting holes: Accept #10 Screw
- Stud material: Tinned Copper
- Stud torque: 120 in-lb (13.56 Nm)
- Terminal stud size: 3/8" - 16 (M10)
