Airmar TM260 Transom Mount Transducer 1kW 50/200kHz

#9004919
Warranty Badge - 24-Months
Check Below for Availability

Seen a lower price? Ask us to beat it

Product Name Price Qty
Airmar TM260 Transom Mount Transducer 1kW 50/200kHz for Furuno 10-Pin

Hurry! 4 left in stock - Ready to Ship

NOW $1,469.00
Airmar TM260 Transom Mount Transducer 1kW 50/200kHz for Garmin 6-Pin

Ships May 24 - Jun 13

$1,459.00 NOW $1,049.00
Airmar TM260 Transom Mount Transducer 1kW 50/200kHz for Garmin 8-Pin

Ships May 24 - Jun 13

NOW $1,659.00
Airmar TM260 Transom Mount Transducer 1kW 50/200kHz for Lowrance/Simrad

Hurry! 3 left in stock - Ready to Ship

$1,419.00 NOW $1,279.00
Airmar TM260 Transom Mount Transducer 1kW 50/200kHz for Raymarine A-Series

Hurry! 1 left in stock - Ready to Ship

NOW $1,529.00
Add Items to Cart

Click on the image above to view full picture

More Views

Details

Details

Powerful and sensitive

The transom mount version of the B260, the top-of-the-line broadband Airmar TM260 Transom Mount Transducer brings crystal clear imaging to your fishfinder. The large 200 kHz element and the seven-element, 50 kHz array are excellent for bait and game fish separation along with detecting ground fish holding tight to the bottom. The TM260’s rugged mounting bracket is easy-to-install and has a streamlined shape that delivers high-speed performance up to 30 knots (35 MPH).

Airmar TM260 Transom Mount Transducer Features:
  • Top-of-the-line narrow-beam transom-mount
  • Designed for bottom fishing
  • Wide 19° beam at 50 kHz
  • Narrow 6° beam at 200 kHz
  • Interfaces to any 600 W or 1 kW sounder
  • Depth and fast-response water-temperature sensor
  • Kick-up assembly locks in the “up” position and willnot damage the transom
  • Accommodates transom angles between 3° and 21°
  • Urethane housing
  • Boat Size: Up to 12 m (40’)

Airmar TM260 Transom Mount Transducer Specifications:
  • Weight: 4 kg (8.9 lb)
  • Hull deadrise: Up to 28°
  • Acoustic window: Urethane
  • Maximum depth range:
    50kHz: 529 to 735m
    200kHz: 206m to 294m

1) AIRMAR TM260 For Lowrance Models: HDS Carbon models , HDS Gen2 and 3 models, HDS-9, HDS-10, HDS-5, HDS-5x, HDS-7, HDS-8, LCX-110C, LCX-111C HD, LCX-112C, LCX-113C HD, LCX-17M, LCX-20C, LCX-25C, LCX-26C HD, LCX-27C, LCX-28C HD, LCX-38C HD, LMS-335C DF, LMS-337C DF, LMS-339C DF iGPS, LMS-480, LMS-525C DF, LMS-527C DF iGPS, X105C DF, X107C DF, X126DF, X136DF, X-515C DF, X59DF , SIMRAD NSE

2) AIRMAR TM260 For Furuno 10pin Models: NavNet DDFF1 & BBFF1, GP1850, GP1650, GP7000F, FCV585, FCV620, LS4100, LS6100, GP1600F, GP1610CF, LS6100, FCV600L, Furuno LS6000, Furuno GP1800F

3) AIRMAR TM260 for Raymarine "A" series Models: DS400X, DS500X, DS600X, A50D, A57D, A65D, A70D, DSM25, a65, a67, e7D, c97, e97, c127, e127

4) AIRMAR TM260 for Garmin 6pin Plug: GPSMAP 441s, GPSMAP 541s, GPSMAP 546s, GPSMAP 720s, GPSMAP 740s, GSD 22

5) AIRMAR TM260 for Northstar 6 Pin Plug: for Navman sounders and fishfinders that use the Navman 6-pin transducer connector, including the M121, M81, and the Explorer series, and the Simrad NX.
