EcoFlow Bi-Facial Modular Solar Panel 125W
Buy now, pay later & Finance Options
Find Local Store
Adjustable angle (30-60 degrees) for optimal solar energy collection
Up to 25% conversion efficiency
STC 125W?BNPI 138W
TOPCon solar cells perform well in low light and high temperatures
Built to last with an IP68 waterproof rating
Versatile use for home, backyard, and RV setups
Lightweight: 4 panels weigh only 16.2kg
The EcoFlow 125W bifacial modular solar panel offers 25% efficiency, plug-and-play expansion, and reliable performance in various weather conditions, making it ideal for long-term home and outdoor use.
Perfectly Tailored for Home Use
Long-Lasting Solar Solution for Your Home
With a 30-year lifespan, this durable, low-maintenance solar panel is ideal for home use.
Fully charge EcoFlow DELTA Pro 3(4kWh) in as fast as 3-4 hours with 3 sets of 500W (125W x 4) panels[1].
Revolutionary N-Type TOPCon Solar Cells & Dual-Sided Design
Maximize Energy Generation
With N-Type TOPCon technology, achieve up to 25% conversion efficiency. The dual-sided design generates Max. 138W[2] bifacial output, capturing more solar energy.
Coated with Protective Lamination & Tempered Glass
Durable, All-Weather Design
Built with robust anti-corrosive aluminum frame, TOPCon cells feature 1.1mm ultra-thin tempered glass for excellent light transmission, POE films for UV and moisture resistance, PET backsheets for durability. The panel is IP68-rated with waterproof XT60-W connector, ensuring robust, weather-resistant performance.
Flexible, Lightweight Design for Adjustable Power Needs
The 500W setup weighs only 37 lbs (16.8 kg) . The modular design enables flexible power configuration. For situations requiring less than 500W or a lighter setup, the system can be split into individual panels, offering both flexibility and reduced weight. Featuring 3M Dual Lock Reclosable Fasteners[3], ensures quick and steady assembly, and the protective bag makes transport and storage effortless.
Universally Compatible Solar Cable
Plug and Play with Your Power System
Easily connect to third-party solar systems using the included photovoltaic connector (MC4 compatible?[4]. Safely charge your power systems and portable power stations with XT60 connectors, featuring waterproof, touch-safe, anti-leak technology for reliable performance.
EcoFlow 125W Bifacial Modular Solar Panel Charging Times
What's In The Box
EcoFlow 125W Bifacial Modular Solar Panel
Quick Start Guide, Safety Instructions & Warranty Card
EcoFlow XT60i to XT60i Extension Charging Cable x1
Specifications:
Rated Power: STC 125W (plus or minus 3W) BNPI 138W (plus or minus 3W)
Open Circuit Voltage: 50V
Short Circuit Current: STC 3.2A BNPI 3.4A
Optimal Operating Voltage: 43V
Optimal Operating Current: STC 3ABNPI 3.2A
Recommended Ambient Temperature: -40 degreesC to 85 degreesC
Efficiency: 25%
Bifaciality Coefficients: 80%plus or minus 5%
Weight: Approx. 4.2 kg
Dimensions (LxWxH): 612x1154x22 mm
Maximum System Voltage: 600V DC (IEC/UL)
Cell Type: TOPCon monocrystalline silicon
Connector Type: XT60
Waterproof & Dustproof Rating: Solar Panel IP68 XT-60 Connector IP68
Lifespan: 30 years, 90%
Footnotes:
[1] Tested under optimal conditions.
[2] The maximum combined power output of the 125W bifacial panel is 138W. Under the same lighting conditions, the bifacial panel can generate up to 10% more power on the rear side compared to a single-sided panel, calculated as (138-125)/125 100% = 10.4%.
[3]The term '3M' and 'dual lock' are both trademarks belonging to the 3M Company, also known as the Minnesota Mining and Manufacturing Company.
[4] Included with the 500W (125W x 4) bifacial modular solar panel set.
